Automated Filter Integrity Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Testing Standards
ASTM F838 – Membrane bubble point method
ASTM D5199 – Gas and liquid filtration membrane performance testing
ISO 2548 series – Pressure decay and diffusive flow methods
GMP/GDP Filter Validation Guidelines
FDA 21 CFR Part 11 – Data integrity compliance
Product Specifications
| Parameter | Technical Specifications |
|---|---|
| System Size | 1189 × 575 × 856 mm |
| System Weight | Approx. 120 kg (empty water tank) |
| Water Tank Capacity | 18 L (removable, manual/automatic filling) |
| Forward Flow Test Accuracy | ±3% or ±0.05 mL/min (whichever is larger) |
| Water Intrusion Test Accuracy | ±3% or ±0.02 mL/min (whichever is larger) |
| Bubble Point Test Accuracy | ±3% |
| Power Supply | 100–240 VAC, 50/60 Hz, typical power 150 W |
| Compressed Air Pressure | 4500–8000 mbar (58–116 psi) |
| Test Flow Range | FF: 0.1–1000 mL/min; WIT: 0.02–50 mL/min; BP: 400–6500 mbar |
| Test Resolution | FF: 0.1 mL/min (<10 mL/min: 0.01 mL/min); WIT: 0.01 mL/min; BP: 50 mbar |
| Touch Screen | 26.4 cm diagonal, 1024 × 768 pixels, backlit, adjustable contrast |
| Protection Level | IP54 (splash-proof) |
| Environmental Conditions | Operating temperature: 5–50℃; Storage temperature: -20–70℃; Relative humidity: 95% RH (non-condensing) |
MUX Expansion Module Specifications
| Parameter | Technical Specifications |
|---|---|
| Model | AW04 |
| Size | 680 × 650 mm, height approx. 1100 mm |
| Materials | Piping: Stainless steel 1.4435/1.4404; Frame: Stainless steel 1.4301; Clamp gasket: EPDM (FDA); Wet contact hose: PTFE (FDA) |
| Maximum Pre-Installed Filter Quantity | 4 liquid filter housings |
Product Features
Fully automated operation: complete automatic wetting, testing, and drainage of filters.
Time-saving: automatic testing reduces testing time by over 50% while maintaining accuracy.
Safe and environmentally friendly: only water is used; no alcohol required, reducing flammable liquid risk.
Remote operation: supports PLC, SCADA, and OPC UA protocols for centralized control and monitoring.
High-precision flow measurement: ensures accurate and repeatable low flow detection.
Self-diagnostic and verification: daily automatic checks for valves, sensors, internal regulators, and data integrity.
Fault detection: automatic alarms for low flow, abnormal pressure, or leakage, minimizing false readings.
Compatible with multiple membrane types: hydrophobic, hydrophilic, and multi-layer composite membranes.
Paperless record-keeping: results can be stored electronically, printed, and exported as PDF/XML files compliant with GMP.
Accessories and Consumables
| Name | Model/Specification | Quantity | Unit |
|---|---|---|---|
| Built-in Water Tank | 18 L, removable | 1 | piece |
| Thermal Printer | Paper width 112 mm, roll diameter 50 mm | 1 | set |
| Standard Water Connection | Manual/automatic filling | 1 | set |
| MUX Expansion Module | AW04 | 1 | set |
| Liquid Filter Housing | Pre-installed (optional) | 1–4 | pieces |
| Touch Screen Operating System | Embedded Linux | 1 | set |
| Data/Network Cables | USB, Ethernet | Several | pcs |
| Testing Software | Self-developed system | 1 | set |
| User Manual | Included | 1 | set |
Testing Principle
Water Intrusion Test (WIT): Hydrophobic membranes are fully wetted and subjected to air pressure. The water evaporation rate is measured, correlating with bacterial retention capability.
Forward Flow Test (FF): Hydrophilic membranes are fully wetted, and the liquid or gas flow through the membrane is measured to assess filter integrity.
Bubble Point Test (BP): Pressure is gradually increased until continuous bubbles appear, determining pore size and membrane integrity.
Flow Control and Measurement: Flowstar IV volumetric flow metering technology ensures high accuracy and repeatability.
Safety Control: The system automatically detects low flow, downstream pressure anomalies, and leakage to prevent false readings.
Operating Instructions
Ensure compressed air pressure is within 4500–8000 mbar before operation.
Water intrusion tests require only deionized water or water of equal quality; avoid alcohol or other liquids.
Hydrophilic filters must be fully wetted before testing; wetting liquids must be compatible with process.
Avoid large temperature fluctuations to maintain accurate gas flow measurements.
System self-check is recommended on first startup; periodic calibration of Flowstar IV flow meters is advised.
When using MUX modules, ensure filter housings are securely connected without trapped air.
Experimental Procedure
Water Intrusion Test (WIT)
Connect the filter housing to the system.
Check the water tank level and prepare deionized water.
The system automatically fills the filter and seals it.
Apply air pressure and measure the water evaporation rate.
Drain the system and automatically generate an electronic test report.
Forward Flow Test (FF) and Bubble Point Test (BP)
Fully wet the filter membrane.
Measure the liquid or gas flow through the membrane and record flow data.
For BP testing, gradually increase pressure until continuous bubbles appear.
The system automatically determines pass/fail for integrity and generates an electronic report.
MUX Expansion Module Operation
Connect 1–4 filter housings to the MUX module.
The system automatically cycles through each filter, recording and storing all test data.
