Film Heat Shrinkage Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
The film heat shrinkage rate tester is mainly used to test the heat shrinkage performance and dimensional stability of various film materials, heat - shrinkable tubes, pharmaceutical PVC sheets, backplanes, etc. in liquid media at multiple temperatures. By precisely measuring the dimensional changes of the film before and after heating and calculating its heat shrinkage rate, the heat shrinkage performance of the material can be evaluated. This performance is directly related to the quality and reliability of products. In the packaging industry, such as in the fields of food, beverages, cosmetics, etc., film materials are widely used for product packaging. The quality of their heat shrinkage performance directly affects the packaging effect and product safety. Through the testing of the film heat shrinkage rate tester, problems that may occur during the heat shrinkage process of materials, such as uneven shrinkage and failure to meet the shrinkage rate standard, can be promptly identified and resolved, thus ensuring the quality of packaging materials.
Standards
ASTM D2732: Standard Test Method for Unrestrained Linear Thermal Shrinkage of Plastic Film and Sheeting
ISO 14616:1997: Plastics — Heat shrinkable films of polyethylene, ethylene copolymers and their mixtures — Determination of shrinkage stress and contraction stress
DIN 53369: Testing of plastic films; determination of the shrinking stress
GB/T 13519-2016:Polyethylene heat-shrinkable film for packaging applications
Features
Digital P.I.D. temperature control technology ensures the preset temperature to be reached rapidly without any fluctuation
The instrument is heated through fluid medium, which could provide the stable test environment
Automatic timer function to efficiently guarantee the accuracy of test data
The instrument is controlled by micro-computer with LCD, PVC operation panel, and menu interface
Standard clamp wire mesh support could make the test done smoothly
Technical Parameters
| Items | Specifications |
| Specimen Size | ≤140 mm x 140 mm |
| Temperature Range | Room temperature ~ 200°C |
| Accuracy | ±0.2°C |
| Power Supply | AC 100-240V 50/60Hz (can be changed to local requirement) |
| Instrument Dimension | 440 mm (W) x 370 mm (D) x 310 mm (H) |
| Net Weight | 24 kg |
Accessoriess
Standard Configurations: Instrument, Micro Printer, 1 Set of Clamp Wire Meshes
Optional Parts: Clamp Wire Mesh and Clamp Wire Mesh Support
