Bag Plastic Buckle Durability Tester
It is mainly used to test the service life of plastic plug-ins in luggage accessories.
Applications
This machine simulates the use of plastic clasp under reciprocating open and close movement to a specified number of times at a certain frequency. And testing the quality of plastic clasps for luggage and clothing.
Standards
QBT 5247-2018:Hardware fitting of case and bag-Test method for durability of plastic buckle
Features
1. We have a strong after-sales service team;
2. We can handle various problems promptly and efficiently, relieving our customers of any worries;
3. We have a complete range of spare parts, eliminating the hassle of long lead times for ordering parts;
4. We keep up with industry standard updates and provide testing instruments that meet the latest standards in a timely manner.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control System | PLC+ Touch Screen (Man-machine interface control system with easy operation and power-off saving function) |
| Counting | 0——999 999 times, automatic stop function when reaches set amount and setting the insertion and extraction times functions in the man-machine interface |
| Drive Motor | High precision servo motor control, stable speed, lower noise, long life span. The right fixture seat can be controlled to left and right movement and positioning speed and angle is accurate than ordinary cylinder |
| Frequency of the Right Clamp | 25±1/ min |
| Open and Close Cylinders | 2 yadeke cylinders |
| Cushion Hydraulic Cylinder | 2 |
| The Right & Left Clamps | Convenient to adjust the samples under different position. This structure adopts a combination of mechanical and pneumatic design |
| Air Supply | exceeding 6kg/cm² |
| Servo Motor | 400w |
| Power Supply | Single phase, AC220V, 50/60HZ |
Accessoriess
It consists of two sets of sample clamps, left and right. The left sample clamp fixes the upper part of the connector and can periodically press the locking mechanism of the connector (left and right locking or up and down locking); the right sample clamp cooperates with the left one to make the upper and lower parts of the connector move horizontally back and forth, with adjustable movement frequency.
1. Counter: Records the number of opening and closing cycles; one opening and closing cycle counts as one time.
2. Control device: It has an automatic stop function in case of sample abnormality during the test and also has a memory function.
Test Procedures
To ensure the long-term stable operation of the testing machine, the following maintenance procedures should be performed regularly:
1. Accuracy Calibration
Calibrate the equipment annually using calibration weights and a torque wrench, keeping the error within 3%.
2. Cleaning and Maintenance
Cover the machine with a dust cover after each use, regularly clean dust from the drive bearings and guide rails, and perform lubrication maintenance every 9 million cycles.
3. Fixture Replacement
For recycled plastics containing additives or high-temperature flame-retardant materials, calibrate the parameters separately and replace with suitable fixtures.
4. Safety Protection
Ensure the equipment is properly grounded, avoid direct exposure of antibacterial components to ultraviolet light, and prevent changes in material properties from affecting test results.
Send product request
Other supplier products
 |
Stapler Blade Sharpness Tester | It features a 7-inch K600+ core/dot-matrix 65-color 800*480 resolution touchscreen display with English and Chinese menu options. Test parameters, ... |
 |
Programmable Ozone Test Chamber | study the effects of ozone on rubber, and then identify and evaluate the method to resist ozone and aging for rubber, adopt effective anti-aging me... |
 |
Electrode Electrolyte Wetting Testing System | The Electrode Electrolyte Wetting Testing System is a high-precision instrument designed to evaluate the wetting behavior of electrolytes on lithiu... |
 |
Desktop Xenon lamp aging test chamber | TheXenon lamp aging test chamberis a photoaging tester for large-capacity textile testing. With additional sample light frame, temperature sensor a... |
 |
