Compression Tester STD - FB3 - A
TheCompression Tester analyzes hand movements-particularly, pushing with a finger-performed by artisans and professionals when judging a fabric' s texture. This device performs this movement mechanically, making it possible to obtain objective numerical data.
Obtainable data includes compression rigidity, compression energy, and recoverability for such targets as general fabric, cloth, paper, and non-woven fabric.
Compression characteristic data is useful for determining fullness and softness, smoothness, anti-drape stiffness.
Standards
ASTM D903. ASTM E8 CNS11888. JIS K6854. PSTC7 ASTM D903、GB/T16491CNS-11888、JIS K6854. PSTC-7 、ASTM E4、ASTM D828、ASTM D882、ASTM、D1938、ASTM D 412 、ISO 8339、ASTM D3330、ASTM F88、ASTM F904、ISO 37、JIS P8113、QB/T 2358、QB/T 1130 、 ISO 527 、ISO 178 and other standards.
Features
Measurement can be performed with a minimum load detection of 10 gf/cm² for extremely small objects.
Parameter
| Product Name | Compression Tester |
| Dimensions (W×D×H) *approx. | Measuring unit: 285×405×500 mm Amplifier: 230×450×500 mm |
| Weight *approx. | Measuring unit: 40 kg Amplifier: 20 kg |
| Power supply, Frequency | 100VAC, 50/60Hz |
| Interface | KES-USB (optional) PC (optional)*1 Data logger output terminal |
| OS | Windows 7/8/8.1/10 |
| Sample size | Square with a side of 100 to 200 mm (standard) |
