SI80 Carbon Arc Aging Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Material Science: Accelerated aging tests for polymers, coatings, and textiles.
Automotive Industry: Validation of exterior components (e.g., bumpers, trim) against UV degradation.
Construction Sector: Weatherability testing for roofing materials, sealants, and facades.
Quality Control: R&D and batch testing for paint, ink, and packaging durability.
Standard
Complies withJIS A1415.B7753.D0205.G3312.H86885.K2246.K5400.Z9117.ISO 4892-1.ASTM G23.AATCC, andNCCAstandards, ensuring global compliance for accelerated weathering tests of materials exposed to sunlight and moisture.
Product Advantages
Accelerated Aging Simulation: Mimics years of natural sunlight/rain exposure in weeks, reducing R&D timelines for material durability testing.
Dual-Environment Testing: Combines high-energy carbon arc light (255 W/m²) with programmable water spray (0.08–0.13 MPa) for realistic outdoor condition replication.
Precision Irradiance Control: Maintains stable arc voltage (50V ±2V) and current (60A ±2A) via PLC-driven feedback systems, ensuring test repeatability.
High-Capacity Throughput: Accommodates up to 76 samples (150×70 mm) on a rotating 960 mm diameter frame, optimizing lab efficiency.
Industrial-Grade Durability: Imported carbon rods and corrosion-resistant chamber (375 kg) withstand continuous 78-hour testing cycles.
Product Features
Advanced Light Source:
4 pairs of carbon electrodes generate discharge arcs, filtered to replicate sunlight’s UV-visible spectrum.
Adjustable irradiance (255 W/m²) and blackboard temperature (63°C/83°C ±3°C) for diverse test protocols.
Environmental Simulation:
Programmable humidity (50% RH ±5%) and 16°C ±5°C water spray for condensation/rain effects.
480 mm arc-to-sample distance ensures uniform exposure across all 76 test positions.
Smart Control System:
7-inch color LCD touchscreen with ICON-based interface for intuitive test setup (e.g., ASTM G23 cycles).
Data logging of irradiance, temperature, and cycle duration for ISO/JIS compliance reporting.
Safety & Maintenance:
Multi-level protection: Overcurrent, overvoltage, leakage, and overtemperature alarms.
Self-diagnostic system alerts for carbon rod replacement and water quality issues.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Automatic (PLC + HMI) |
| Carbon Arc Duration | 78 hours (continuous) |
| Discharge Voltage | 50 V ±2 V |
| Discharge Current | 60 A ±2 A |
| Irradiance | 255 W/m² (adjustable) |
| Blackboard Temperature | 63°C ±3°C or 83°C ±3°C |
| Water Spray | 0.08–0.13 MPa; 2100 mL ±100 mL/min (16°C ±5°C) |
| Chamber Humidity | 50% RH ±5% |
| Sample Capacity | 76 × 150×70 mm specimens |
| Rotation Speed | 1 RPM (uniform exposure) |
| Power Supply | 380 VAC ±10%, 50 Hz, 15 kVA |
| Dimensions | 1650 × 1500 × 2200 mm (L×W×H) |
| Weight | 375 kg |
| Safety Certifications | CE, UL, and RoHS compliant |
