Humidity Environmental Test Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1.Wide Humidity & Temperature Range
Offers precise control over humidity from 20% to 98% RH and temperature from -70°C to +150°C, simulating real-world environmental extremes with accuracy.
2.Stable and Uniform Control
Utilizes advanced PID controllers and balanced temperature-humidity control (BTHC) systems to ensure consistent environmental conditions across the test space.
3.Anti-Corrosion & Durable Design
Interior is made of SUS304 stainless steel with mirror finish, highly resistant to corrosion and suitable for long-term, high-humidity operation.
4.Customizable Configurations
Chambers can be tailored in size, door style, port locations, or humidity response speed to meet non-standard test specifications.
5.Compliance with International Standards
Fully compliant with IEC, MIL, ASTM, and ISO humidity test standards, ensuring global acceptance of test results.
Specifications
|
Model |
STD TH-100 |
STD TH-225 |
STD TH-500 |
STD TH-1000 |
|
Internal Dimension (mm) |
400*500*500 |
500*600*750 |
700*800*900 |
1000*1000*1000 |
|
Overall Dimension (mm) |
900*1050*1620 |
1000*1140*1870 |
1200*1340*2020 |
1500*1540*2140 |
|
Interior Volume |
100L |
225L |
500L |
1000L |
|
Heat load |
1000W |
|||
|
Temperature Range |
A : -20℃～+150 ℃ B : -40℃～+150 ℃ C: -70℃～+150 ℃ |
|||
|
Temperature Fluctuation |
± 0.5 ℃ |
|||
|
Temperature Deviation |
± 2.0 ℃ |
|||
|
Humidity Range |
20% ~ 98% RH |
|||
|
Humidity Deviation |
± 2.5% RH |
|||
|
Cooling Rate |
1 ℃ / min |
|||
|
Heating Rate |
3 ℃ / min |
|||
|
Controller |
Programmable color LCD touch screen controller,PC Link, LAN interface for remote control |
|||
|
Cooling system |
Mechanical compression refrigeration system |
|||
|
Refrigerant |
Environmentally friendly refrigerant |
|||
|
Water supply system |
Automatic water supply; Water purification system |
|||
|
Safety device
|
Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; |
|||
|
Interior Material |
SUS304 stainless steel |
|||
|
Exterior Material |
Steel Plate with protective coating |
|||
