Midsole Fibreboard Bending Test Machine - STD G664
Product Introduction:
G664 mid-sole fiberboard zigzag testing machine Test leather shoes and casual shoes, walking shoes and other travel shoes, mid-sole fiberboard zigzag resistance quality.
One end of the sample of shoe fiberboard material is hung in a weight, and one end is fixed in the fixture is continuously reciprocated to the left and right each bending 90 degrees, testing a certain number of times until the break, the number of breaks to determine the flexion index of the bottom plate, as a basis for comparison and selection of the bottom plate.
Reference standard:
QB/T 1472. BS 5131:4.2. SATRA TM3. PM4. PM5. PM6. PM15. PM16. QB/T4329-2012 standard
Product Advantages:
Measures Key Durability: Quantifies the resistance of mid-sole fibreboard to repeated bending and fatigue cracking under tension.
Standard Compliant: Designed to meet relevant national and international standards for testing fibreboard and footwear components (QB/T 1472. BS 5131. SATRA TM3. etc.).
Quantitative Result: Provides an objective numerical result (cycles to break/flexion index) for comparing material performance.
Multiple Testing Stations: Allows simultaneous testing of 6 samples, significantly increasing testing throughput.
Controllable Test Parameters: Enables precise control of the bending angle, speed, and applied tension (via the weight).
Automatic Counting: The integrated counter automatically tracks the number of cycles until sample failure.
Precise Speed Control: The variable frequency motor ensures stable and accurate flexing speed.
Product Features:
Multiple test fixtures/stations (6) for simultaneous testing.
Clamping mechanism at one end of each station to fix the fibreboard sample.
System at the other end of each station to attach a weight (approx. 2kg including clamp) to apply tension to the sample.
Mechanism for continuous reciprocating bending of the samples through a 90° angle.
Controllable flexing speed (60 ± 10 r/min) driven by a variable frequency motor.
LCD digital counter for each station (up to 999.999 cycles) to record cycles to sample break.
Sample holders with specified upper and lower clip lengths (15mm and 10mm) to hold the 80x10mm test piece.
Designed for testing fibreboard samples of a specific size (80x10mm).
Technical specifications:
1. Test fixture: 6
2. Test piece: 80×10mm
3. Reciprocating Angle: 90°
4. The weight includes the clamp: (2±0.01kg)×6
5. Tortuous speed: (60±10)r/min
6. Counter: LCD, 0——999999(7 groups)
7. Sample holder: upper clip length 15mm, lower clip length 10mm
8. Motor: variable frequency motor
9. Volume: 109×26×34cm
10. Power supply: 1∮，AC220V,3A
