Stapler Blade Sharpness Tester YY/T 1797
The Sharpness Tester for Stapler Blades plays a crucial role in the medical device field. The following is a detailed introduction to its compliance standards,main uses, and technical parameters:
Compliance Standards
YY/T 1797 - 2021. etc.
Main Uses
The sharpness tester for stapler blades is mainly used to assess the sharpness of blades for medical staplers, ensuring the quality of surgical instruments and the surgical outcome. Specifically, the tester simulates the process of the blades cutting materials, measures and analyzes parameters such as the force and displacement during cutting, and then determines the sharpness value of the blades. This test result not only provides important quality - control evidence for medical device manufacturers but also offers reliable reference data for medical workers when choosing surgical instruments.
Technical Parameters
Testing Accuracy: ±0.01N
Testing Speed: 0.05
600mm/min (Some models may vary, such as 600mm/min±30mm/min)
Testing Material: Complies with the 3 - 0 suture made of silk - like twisted strands without coating as specified in YY0167 - 2005 (or other standard testing materials)
Power Supply: 220V 50Hz - Overall Power Consumption: 70W (or other values)
External Dimensions: 400×290×275mm (or other dimensions)
Net Weight: 15kg (or other values)
