Fabric Surface Combustion Performance Tester ISO 10047:1993 GB/T 8745-2001

Standards:

For different standards, different accessories are required . GB/T 8745-2001 Textile. Combustion performance. Determination of surface burning time of fabrics ISO 10047:1993 Textiles. Determination of surface burning time of fabrics

Applications:

Suitable for measuring the surface burning time of textile fabrics with fluff (for example, pile, loop, tuft or similar surface) on the surface

Product Information:

Main features:

1. Electric wire ignition.

2. automatic timing positioning for burner

3. arbitrarily set the ignition time for 0 ~ 99.99 seconds. Automatically record the burning time, digital display.

Specifications:

1. sample holder: length 150mm × width 75mm

2. the frame mark line: the sample is located under the ignition 75mm

3. the ignition time: 0 ~ 99.99 seconds arbitrarily set

4. flame height measurement device: flame height 40 ± 2mm

5. the ignition tip from the specimen holder surface distance: 15mm

6. the use of gas: industrial butane or propane or butane / propane mixed gas.

7. the sample size: 150mm × 75mm
