Fabric Surface Combustion Performance Tester ISO 10047:1993 GB/T 8745-2001
Standards:
For different standards, different accessories are required . GB/T 8745-2001 Textile. Combustion performance. Determination of surface burning time of fabrics ISO 10047:1993 Textiles. Determination of surface burning time of fabrics
Applications:
Suitable for measuring the surface burning time of textile fabrics with fluff (for example, pile, loop, tuft or similar surface) on the surface
Product Information:
Main features:
1. Electric wire ignition.
2. automatic timing positioning for burner
3. arbitrarily set the ignition time for 0 ~ 99.99 seconds. Automatically record the burning time, digital display.
Specifications:
1. sample holder: length 150mm × width 75mm
2. the frame mark line: the sample is located under the ignition 75mm
3. the ignition time: 0 ~ 99.99 seconds arbitrarily set
4. flame height measurement device: flame height 40 ± 2mm
5. the ignition tip from the specimen holder surface distance: 15mm
6. the use of gas: industrial butane or propane or butane / propane mixed gas.
7. the sample size: 150mm × 75mm
