Spring tension testing machine
Product Introduction:
The spring tension and compression testing machine has accurate loading speed and force measurement range, and has high precision and sensitivity to the measurement and control of load, deformation and displacement. It is mainly suitable for the tensile and compressive force load testing of spring, rubber, reed and other elastic devices under a certain working length.
Applicable standards:
ISO10243 ;
EN13597 ;
JB/T 7796-1995. JB/T 7796-2005 "Spring tensile testing machine test method"
GB/T 13634 "Calibration of Dynamometer for Testing machine calibration"
JIS B7738-1993 "Spiral spring pressure and tension Testing Machine"
Product Advantages:
Accurate Measurement: Provides precise and reliable data on spring force and displacement.
Determines Key Properties: Essential for accurately measuring initial tension and spring rate.
Ensures Product Performance: Helps verify that springs will function correctly in their intended applications.
Quality Control: Enables consistent testing of springs in production to maintain quality standards.
Supports Design and Development: Provides crucial data for designing and optimizing spring performance.
Versatile: Can often test a range of spring sizes and force capacities depending on the machine model and fixtures.
Main parameters:
Force measurement range: 1%——100%FS
Test speed: 0.5——500mm/min
Displacement stroke: 170mm
Spring free length: 170mm
Disc diameter: 50mm
Unit: N, kgf, lbf, ozf
Power supply: AC 220V±10% 50Hz
Operating temperature: 20±10℃
Transport temperature: -27℃——+70℃
