Photovoltaic module outdoor exposure test system
Standard
IEC 61215: Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
IEC 61730: Photovoltaic (PV) Module Safety Qualification
UL 61730: Safety Standard for Photovoltaic Modules
ISO 9060: Solar Energy – Classification of Pyranometers
CE Certification(Conformité Européenne)
Product Advantages
Real-World Accelerated Aging
10–15 Year Equivalence: Achieves IEC 61215 damp heat/UV exposure in 6 months.
Spectral Matching: AM1.5G filter for standardized terrestrial solar simulation.
Multi-Environment Testing
-40°C to +85°C Chamber: Replicates desert heat to polar cold with ±1°C stability.
95% RH Humidity Control: Tests PID resistance in tropical/marine environments.
Energy Harvesting
Grid-Tied Design: Offsets 70% of power consumption via test module output.
MPPT Tracking: Optimizes energy extraction during standby periods.
Smart Data Acquisition
16-Channel Logging: I-V curves, EL imaging, and thermal mapping in real-time.
AI-Powered Diagnostics: Predicts degradation modes (delamination, hotspots) via ML.
Safety First
Arc-Fault Detection: UL 1699B-compliant for DC side protection.
Emergency Shutoff: Dual redundant safety circuits with GPS-enabled alerts.
Product Features
Dual-Axis Tracker: ±60° tilt, ±180° azimuth for precise solar alignment.
10” Sunlight-Readable HMI: Preloaded IEC/UL test sequences with customizable dwell times.
Remote Monitoring: 4G/LTE connectivity with SMS/ alerts.
Self-Cleaning System: Automated rain simulation for dust accumulation studies.
Modular Design: Expandable from 5 kW to 50 kW for pilot-scale testing.
Accessories Included
Testing Kit:
4x IEC 60904-4 compliant reference cells.
10x Type T thermocouples with ceramic insulation.
Software Suite:
License key forSolarTest Pro(Windows/Linux).
1-year free access to cloud-based PV simulation tools.
Calibration & Safety:
NIST-traceable irradiance meter.
Arc-flash protective gear (Class 2. 3 pairs).
Maintenance Kit:
Spare fuses and surge protectors.
Chamber cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for IEC/UL/ISO standards
Technical Parameters
| Parameter | Specification |
|---|---|
| Solar Irradiance | 300–1.200 W/m² (AM1.5G filtered) |
| Temperature Range | -40°C to +85°C (operational) |
| Temperature Deviation | ≤±1°C (at steady state) |
| Humidity Range | 10%–95% RH (non-condensing) |
| Chamber Volume | 2m × 3m × 2.5m (W×D×H, expandable) |
| Power Supply | 380V/415V 3-phase, 50/60Hz |
| Dimensions | 2.500mm (W) × 3.500mm (D) × 3.000mm (H) |
| Weight | 1.200 kg (net) / 1.800 kg (gross) |
