Vertical low temperature cold resistance tester
Product description:
This machine is used to test finished shoes, rubber, plastic, soles, synthetic leather and other cold resistance degree to understand the material or finished products to adapt to low temperature climate or cold areas, this machine is made of stainless steel and can be installed with a variety of resistant fixtures to apply to different requirements.
Standards:
ASTM-D1790. D1593.1052. JIS-K6545. HB-T2877. CNS-7705. ISO 20344. GB/T20991-2007
Product Specifications:
1. Inner and outer box material: stainless steel #304
2. Controller: touch screen control
3. Temperature range: (1) normal temperature -30℃ (2) normal temperature -50℃(optional)
4. Optional inner box action: leather flex fixture (optional to install finished shoes with bending resistance, outsole zigzag resistance fixture)
5. Protection device: thermal protection stop, leakage protection stop overtemperature protection, overload protection and other functions
6. Control accuracy: ±0.3℃
7. Distribution uniformity: ±0.1℃
8. Cooling speed: from room temperature to -30℃
9 Refrigerant: R404 environmental refrigerant
10. Compressor: original fully hermetic
11. Compressor starting delay: 5min
12. Power consumption: (4-6)KW
13. Insulation material: rigid foam and glass wool
14. Counter: LCD,0——999.999
15. Window: (210×35×270)mm, two vacuum layer
16. Window light: P1 light,5W
17. Power supply: AC380V 50Hzor1 AC220V 50HZ
18. Motor: no belt multi-import gear reducer motor
19. Inner box size: (600×600×550) mm
20. Volume: (110×105×160) cm
21. Weight: 200kg
