Computer-controlled Helmet Impact meter
Application Scope
This testing instrument is applicable to the impact - energy absorption performance test of helmets. It is used to evaluate the impact - resistance performance and penetration - resistance of helmets.
Standard
GB 811 GB 24429
GB/T 38305-2019 GA 44
IS 4151 (India)
DOT FMVSS No. 218 (USA)
ECE R22.05 (Europe)
EN 1078 (Cycling helmets)
IS 2925 (Industrial safety helmets)
Specifications
1 System components: consists of a crash test stand and an analysis recorder.
2 Crash test bench: composed of fall guidance device, head type, head type fixed frame, ball joint, anvil, anvil seat, release guidance system and seat base and other components.
3 Impact height: control interface setting, with guidance system, acceleration detection and calibration device (1000 ~ 3000mm can be customized)
4 Base: the optimal solution is made of reinforced concrete, the instrument's steel base is connected to the concrete base, so that its quality is not less than 1600kg.
5 Test and Analysis Instrumentation System: consists of acceleration sensors or impact sensors, amplifiers, and data processing, display and recording, and other components. Part of the composition
Technical Specifications:
Dimensions (L*W*H*H cm): 90*80*450 (according to the order impact height)
Weight (kg): 350
Installation requirements:
1 Power supply: AC 220V 50Hz 500W
2 Environment: 10 ~ 35 ℃
3 Operation: floor, connected to the concrete pedestal
