Mini Rapid Closed Cup Flash Point Analyzer
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Reference Standards：
SN/T 3077.1、SN/T 3077.2.
SH/T 0768.
DL/T 1354.
ASTM D93、ASTM D6450、ASTM D3828、ASTM D7094、ASTM D7236、ASTM D56、ASTM D56、ASTM D93 Procedure A, B and C；
ISO 2719、ISO 13736、ISO 1516、ISO 1523；
IP 34、IP 304、IP 170；
DIN EN 22719;
JIS K2265;
NF M 07-019；
GB/T 261、GB/T 21615、GB/T 5208、GB/T 21790；
Product Features：
1. It adopts the advanced continuous closed - cup flash - point test method, which is more accurate and efficient.
2. It requires a small sample amount, resulting in low test costs and minimal pollution.
3. With continuous closed - cup operation, there is no open flame, ensuring high safety.
4. It has a built - in refrigeration module, offering a wide flash - point test range and a fast cooling rate.
5. Standard test methods are preset and can be associated with other closed - cup methods.
6. It features fully automated detection and automatically corrects the flash - point based on atmospheric pressure.
7. It displays temperature and pressure curves in real - time, making the test process more intuitive.
8. The test results include a temperature - pressure rise curve, providing more information about flash combustion.
9. Key components are from well - known international brands, ensuring long - term stable operation.
10. It supports user - level management, enabling the management and control of accounts at different levels.
11. The USB interface is plug - and - play. An optional thermal printer is available for convenient data management.
12. It is equipped with a 7 - inch color touch screen that supports Chinese input, making the operation intuitive and simple.
Technical parameters:
|
Operating Environment |
(5～40)℃, <85%RH |
|
Temperature Range |
(0～260)℃ |
|
Rising Rate |
(-30～260)℃ (with low-temperature module) |
|
Temperature Detection Accuracy |
(0～420)℃ (with high-temperature module) |
|
Pressure Detection Range |
(-30～420)℃ (with low-temperature and high-temperature modules) |
|
Sample Volume |
(2.5±0.3)℃/min, (5.5±0.5)℃/min, |
|
Ignition Method |
(0.5～12)℃/min Customized |
|
Stirring Speed |
±0.1℃ |
|
Storage Space |
(0～200)kPa |
|
Interface |
1mL or 2mL |
|
Power |
High-pressure electronic ignition |
|
Power |
(50~300)rpm software can be set |
|
Dimensions |
5000 test results |
|
Weight |
RS232*1. RJ45*1. USB*2 |
