Car seat component clearance test bench

Applicable standards:

Car seat component clearance test benches usually follow the following domestic and international standards:

QC/T 805-2008 "Passenger Car seat slide Technical conditions" and other relevant seat components of the technical conditions and testing requirements.

Main parameters:

Measuring range:

Depending on the specific type and size of the seat component, the measuring range of the test bench should be able to cover the size of the clearance required to be measured. For example, for the measurement of the seat slide gap, the test bench should be able to accurately measure the loose gap of the slide in the right and left, up and down, front and back directions.

Measurement accuracy:

The measurement accuracy of the test bench shall meet the requirements of relevant standards and regulations. Generally speaking, the measurement accuracy of the displacement sensor should reach ±0.1mm or higher to ensure the accuracy and reliability of the measurement results.

Loading force:

In the clearance measurement, it may be necessary to apply a certain loading force to simulate the force of the seat in actual use. The test bench should be able to provide a stable loading force and be able to adjust within the specified range.

Test speed:

The test speed should be set according to the specific test requirements and standards. In general, the test speed should be able to be adjusted within a certain range to adapt to the testing needs of different parts.

Data acquisition and processing:

The test bench should have the function of data acquisition and processing, which can record the data in the test process in real time, and carry out data processing and analysis. This helps to assess the conformity and consistency of the clearance of the seat components.

Degree of automation:

Modern automotive seat component gap test stands usually have a high degree of automation, and can automatically complete the test process, data recording and processing. This helps improve test efficiency and accuracy.

Safety and Reliability:

The test bench should have perfect safety protection measures and reliable mechanical structure to ensure the safety and reliability of the test process. For example, safety measures such as emergency stop button and overload protection device should be set up.
