High precision vehicle sunshade assembly machine

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Standards

The system is designed and manufactured in accordance with relevant international and automotive industry standards, including:

(1) ISO 9001 — Quality management systems

(2) IATF 16949 — Quality management system for automotive production

(3) ISO 12100 — Safety of machinery

(4) IEC 60204-1 — Safety of machinery electrical equipment

(5) ISO 13849 — Safety-related parts of control systems

(6) ISO 16750 — Environmental conditions and testing for automotive electrical equipment

Parameters

Item	Specification
Assembly Mode	Fully automated, multi-station continuous assembly
Process Integration	Dozens of assembly processes integrated into one line
Fastening Method	Program-controlled screw fastening with torque verification
Detection System	Non-contact 3D laser inspection system
Drive System	EMS + VAC material handling system
Motion System	Friction Drive System (FDS)
Noise Level	Low-noise operation suitable for interior assembly
Testing Capability	Functional inspection and environmental simulation
Production Mode	Continuous flow production from components to finished sunshades
Layout Type	Modular, space-saving configuration

Features

Automated assembly reduces manual labor and improves production efficiency.

Integrated multi-process design enables continuous production from components to finished sunshades.

Non-contact 3D laser inspection ensures high dimensional accuracy and repeatability.

Friction drive system provides clean, lubrication-free, and quiet operation.

Modular system design allows flexible customization and future expansion.

Accessories

(1) EMS + VAC material handling system

(2) Friction Drive System (FDS) modules

(3) Non-contact 3D laser inspection heads

(4) Automated screw fastening and torque monitoring units

(5) Rain simulation and functional test equipment

Test Procedures

Load sunshade components into the storage area.

Transfer parts automatically to assembly stations via the material handling system.

Perform automated assembly and fastening under program control.

Inspect assembled sunshades using the non-contact 3D laser system.

Conduct functional and sealing tests as required.

Transfer qualified products to the off-line area.

Maintenance Information

Inspect drive and handling systems regularly to ensure stable operation.

Clean laser inspection heads to maintain measurement accuracy.

Check fastening tools and torque control systems periodically.

Verify control software and safety interlocks during routine maintenance.

Perform preventive maintenance based on operating hours and production load.
