High precision vehicle sunshade assembly machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
The system is designed and manufactured in accordance with relevant international and automotive industry standards, including:
(1) ISO 9001 — Quality management systems
(2) IATF 16949 — Quality management system for automotive production
(3) ISO 12100 — Safety of machinery
(4) IEC 60204-1 — Safety of machinery electrical equipment
(5) ISO 13849 — Safety-related parts of control systems
(6) ISO 16750 — Environmental conditions and testing for automotive electrical equipment
Parameters
| Item | Specification |
|---|---|
| Assembly Mode | Fully automated, multi-station continuous assembly |
| Process Integration | Dozens of assembly processes integrated into one line |
| Fastening Method | Program-controlled screw fastening with torque verification |
| Detection System | Non-contact 3D laser inspection system |
| Drive System | EMS + VAC material handling system |
| Motion System | Friction Drive System (FDS) |
| Noise Level | Low-noise operation suitable for interior assembly |
| Testing Capability | Functional inspection and environmental simulation |
| Production Mode | Continuous flow production from components to finished sunshades |
| Layout Type | Modular, space-saving configuration |
Features
Automated assembly reduces manual labor and improves production efficiency.
Integrated multi-process design enables continuous production from components to finished sunshades.
Non-contact 3D laser inspection ensures high dimensional accuracy and repeatability.
Friction drive system provides clean, lubrication-free, and quiet operation.
Modular system design allows flexible customization and future expansion.
Accessories
(1) EMS + VAC material handling system
(2) Friction Drive System (FDS) modules
(3) Non-contact 3D laser inspection heads
(4) Automated screw fastening and torque monitoring units
(5) Rain simulation and functional test equipment
Test Procedures
Load sunshade components into the storage area.
Transfer parts automatically to assembly stations via the material handling system.
Perform automated assembly and fastening under program control.
Inspect assembled sunshades using the non-contact 3D laser system.
Conduct functional and sealing tests as required.
Transfer qualified products to the off-line area.
Maintenance Information
Inspect drive and handling systems regularly to ensure stable operation.
Clean laser inspection heads to maintain measurement accuracy.
Check fastening tools and torque control systems periodically.
Verify control software and safety interlocks during routine maintenance.
Perform preventive maintenance based on operating hours and production load.
