Flatbed Ironing Tester | Textile Testing Equipment
Product Overview
TheFlatbed Ironing Testeris a precision instrument designed to evaluate fabric performance under simulated ironing conditions. It measures heat resistance, crease recovery, and shrinkage resistance, providing critical data for textile quality control and R&D applications.
Type: Bench-top thermal testing equipment
Temperature Range: Ambient +20°C to 300°C
Pressure Control: 0.5-5 kPa adjustable (simulates iron weights)
Test Area: 300×300mm heated flatbed
Applications: Apparel, home textiles, industrial fabrics
Compliance Standards
ISO 3758 (Textile care labeling)
ASTM D1683 (Fabric wrinkle recovery)
AATCC 117 (Flammability resistance)
GB/T 3917.3 (Chinese textile shrinkage standard)
Key Features
Multi-Test Modes:
Crease Recovery Test:Measures angle retention after 5min pressing
Shrinkage Test:Evaluates dimensional stability at 180°C
Heat Setting Test:Simulates industrial ironing conditions
Digital Control System:
7-inch touchscreen interface
Programmable 100-step test sequences
Real-time data logging (CSV export)
Safety Features:
Overheat protection (auto-shutdown at 310°C)
Interlock door switch
Grounding indicator
Applications
Quality Control:Batch testing of finished fabrics
R&D:Developing wrinkle-resistant treatments
Textile Education:Training on heat treatment effects
Forensic Analysis:Evaluating garment damage causes
Technical Specifications
| Parameter | Specifications |
|---|---|
| Heating Rate | 10°C/min (programmable) |
| Cooling System | Forced air cooling (30°C recovery in 5min) |
| Power Supply | 220V/50Hz, 1.5kW |
| Dimensions | 600×500×1200mm (W×D×H) |
| Weight | 45kg |
| Temperature Uniformity | ±2°C across test area |
