Fabric Wrinkle Bending Tester / AATCC 128 / Textile Tester
Overview
The Fabric Wrinkle Bending Tester is a specialized instrument used to assess the wrinkle recovery properties of various textile fabrics. It simulates the conditions that fabrics encounter during actual use, such as pressure and temperature, to evaluate their ability to form and recover from wrinkles
Working Principle
The tester typically employs the vertical or horizontal crease recovery method. During the test, a fabric sample is placed on a testing platform and subjected to a specified pressure for a set duration. After the pressure is released, the instrument records the fabric's wrinkle recovery over time, assessing its wrinkle stability and recovery ability
Key Technical Parameters
Sample Size: Generally 40mm x 15mm or other standard sizes
Pressure Load: Typically around 10N, adjustable as per the test standard
Recovery Angle Measurement Range: 0-360 degrees with a resolution of 1 degree
Test Time: Includes both immediate and delayed wrinkle recovery times, adjustable from 1s to 9999s
Applications
This tester is widely used in:
Textile Production: Identifying and resolving wrinkle issues in seams, cutting, and sewing processes
Clothing Design: Helping designers understand fabric behavior under different conditions to create more consumer-friendly products
Quality Control: Providing critical data for textile enterprises to ensure product quality and compliance with standards
Standards Compliance
The testing methods and results should comply with relevant national or international standards, such as GB/T 3819. ISO 2313. and AATCC 128
