High-Speed Reciprocating Friction and Wear Tester (Model 2M)
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The High-Speed Reciprocating Friction and Wear Tester (Model 2M) is designed for evaluating the friction and wear performance of materials and components. The instrument features a wide load range and adjustable sliding speed, allowing precise assessment of lubrication properties, surface treatments, and material performance under room temperature to 300°C. During testing, friction coefficient, wear depth, surface profile, wear volume, and wear resistance are measured in real time with graphical display and data storage. The tester is user-friendly, equipped with automatic stop protection, and provides high measurement accuracy.
Application
Friction and wear testing of metallic and non-metallic materials.
Evaluation of coatings, surface treatments, and composite material wear resistance.
Material lubrication property testing.
Reciprocating friction testing under high-temperature (up to 300°C) or ambient conditions.
Laboratory research and industrial quality control.
Standards
GB/T 3960-2016 Plastics – Determination of Sliding Wear Properties
ASTM G99 Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus
ASTM G133 Standard Test Method for Linearly Reciprocating Pin-on-Flat Sliding Wear
ISO 20502 Coating Scratch Test
DIN 50324 Friction and Wear Test Standard
Parameters
| Parameter | Specification |
|---|---|
| Test Load Range | 30–1000 g (weight loading), 10–200 N (automatic); accuracy 0.2% F.S. |
| Reciprocating Frequency | 0.1–45 Hz, adjustable |
| Reciprocating Stroke | 0.5–25 mm, adjustable according to frequency |
| Sample Heating Furnace Temp. | Room temperature – 300°C (sample diameter Φ15–40 mm) |
| Test Load in Furnace | 0.3–80 N |
| Friction Force Measurement | ≤100 N |
| Wear Depth Measurement | ±0.5 mm |
| Power Supply | 210–235 V, 50–60 Hz, 2500 W |
| Workbench Size | 1800 × 750 × 800 mm (user-supplied) |
Features
Wide load and adjustable frequency to accommodate various materials and component tests.
Testing possible at room temperature and high temperature up to 300°C.
Real-time measurement of friction coefficient, wear depth, wear volume, and surface profile with graphical display.
Automatic stop protection ensures safe operation.
User-friendly operation with high measurement accuracy, suitable for research and industrial quality control.
