Rotary reciprocating friction and wear tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Reciprocating-Rotary Friction and Wear Tester (Type 1) is designed for evaluating the tribological performance of materials and surface coatings. This device simulates rotational and linear reciprocating motion under a controlled test force. By adjusting parameters such as load, speed, frequency, stroke, duration, friction pair materials, surface roughness, and hardness, you can assess the comprehensive performance of materials or coatings. The system provides real-time monitoring of friction force, test load, and temperature, and dynamically plots all key parameters. Safety functions include automatic shutdown or alarms if preset limits are exceeded.
Applications
You can use this tester to:
Evaluate the tribological performance of material surfaces and coatings
Test wear resistance and friction coefficients of friction pairs, including metals, polymers, and ceramics
Monitor friction force, temperature, and other parameters in real time
Support material research, quality control, and production testing
Standards
ASTM G99 – Standard Test Method for Wear Testing
ASTM G133 – High-Temperature Friction and Wear Test Method
ISO 20808 – Solid Material Friction and Wear Test
GB/T 3147 – Determination of Friction Material Wear Performance
Technical Specifications
| Parameter | Range / Specification |
|---|---|
| Maximum Test Force | 1000 N |
| Maximum Speed | 2000 rpm |
| Maximum Frequency | 200 Hz |
| Maximum Reciprocating Friction Force | 100 N |
| Maximum Rotational Torque | 4.7 Nm |
| Reciprocating Stroke Range | ±6 mm |
| Reciprocating Friction Modes | Ball-on-disk, Pin-on-disk, Cylinder-on-disk |
| Rotational Friction Modes | Ball-on-disk, Pin-on-disk, End-face |
| Temperature Range | Room temperature – 600℃ |
| Notes | Optional micro-force module, ring-block module available |
Features
Dual Friction Modes: Supports both rotational and reciprocating friction, with multiple friction configurations (ball-on-disk, pin-on-disk, etc.)
High-Precision Force Control: Maximum test force up to 1000 N, suitable for high-load testing
Wide Temperature Range: Capable of testing from room temperature up to 600℃
High-Speed & High-Frequency Testing: Up to 2000 rpm and 200 Hz for precise and efficient testing
Real-Time Monitoring: Friction force, test load, and temperature are continuously monitored and plotted
Multiple Friction Pairs: Supports various materials and modules, including micro-force and ring-block options
Safety Protection: Automatic shutdown or alarm if preset limits are exceeded
