Real-time gas monitoring system for battery thermal runaway testing
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Battery Research and Development
Provides controlled thermal runaway testing for lithium battery cells, enabling analysis of gas composition, pressure evolution, and reaction kinetics.
Battery Manufacturing and Quality Control
Evaluates battery safety and consistency under abuse conditions, supporting process improvements and production safety verification.
Battery Safety Certification
Offers standardized testing aligned with UL 9540A for thermal runaway fire propagation, supporting regulatory compliance.
Academic and Industrial Research
Enables detailed study of battery thermal behavior, including gas generation, explosion pressure, and component analysis, facilitating material and system-level research.
Standards
The system is compliant with the following standard:
(1) UL 9540A-2025 – Standard for Testing Thermal Runaway Fire Propagation in Battery Energy Storage Systems
Parameters
| Item | Specification |
|---|---|
| Platform Dimensions | Determined by sample volume requirements |
| Control Cabinet | 650(L) × 675(W) × 1750(H) mm |
| Fourier Transform Infrared (FTIR) System | 650(W) × 675(D) × 1750(H) mm |
| Power Supply | AC 220 V, 30 A |
| Weight | Approximately 900 kg |
| Backup Gas Source | Nitrogen ≥ 99.99% |
Accessories
(1) Multi-layer gas sampling lines
(2) Pressure and temperature sensors
(3) Vacuum pump and nitrogen supply interface
(4) FTIR spectrometer
(5) Electrochemical gas sensors
(6) Heated pipeline assembly
(7) Video monitoring system
(8) Control cabinet with PLC and touchscreen
