G664 fibreboard bending testing machine
Product Introduction:
G664 mid-sole fiberboard zigzag testing machine Test leather shoes and casual shoes, walking shoes and other travel shoes, mid-sole fiberboard zigzag resistance quality.
One end of the sample of shoe fiberboard material is hung in a weight, and one end is fixed in the fixture is continuously reciprocated to the left and right each bending 90 degrees, testing a certain number of times until the break, the number of breaks to determine the flexion index of the bottom plate, as a basis for comparison and selection of the bottom plate.
Reference standard:
QB/T 1472. BS 5131:4.2. SATRA TM3. PM4. PM5. PM6. PM15. PM16. QB/T4329-2012 standard
Technical specifications:
1. Test fixture: 6
2. Test piece: 80×10mm
3. Reciprocating Angle: 90°
4. The weight includes the clamp: (2±0.01kg)×6
5. Tortuous speed: (60±10)r/min
6. Counter: LCD, 0——999999(7 groups)
7. Sample holder: upper clip length 15mm, lower clip length 10mm
8. Motor: variable frequency motor
9. Volume: 109×26×34cm
10. Power supply: 1∮，AC220V,3A
