Export Medical needle toughness tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Application

(1) Medical disposable injection needles – evaluating bending durability before packaging.

(2) Insulin pen needles – testing ultra-thin walls for high flexibility without fracture.

(3) Vacutainer blood collection needles – ensuring mechanical reliability during insertion.

(4) IV infusion needles and cannulas – verifying structural integrity under repeated bending stress.

(5) Specialty surgical needles – quality assurance for orthopedic or microsurgical applications.

Standards

The device meets and supports testing according to the following international and national standards:

(1) GB15811 – Sterile disposable injection needle

(2) GB18457 – Stainless steel needle for medical equipment manufacturing

(3) ISO 9626 – Stainless steel needle for medical use

Test Procedure

(1) Fix one end of the needle tube firmly in the jig.

(2) Adjust the span according to needle wall type:

Normal wall: 25° bending

Thin wall: 20° bending

Ultra-thin wall: 15° bending

(3) Apply force at the specified span position, bi-directionally, 20 times at a frequency of 0.5 Hz.

(4) Observe the needle for breakage, deformation, or failure.

Principle: One end of the needle is fixed. A force is applied from the fixed point to the prescribed span, bending in one direction and then in the opposite direction, repeated for the defined number of cycles.

Technical Parameters

ParameterSpecification
Syringe nominal specifications 0.2 – 3.4 mm
Test frequency 0.5 Hz
Rocker arm bending angle 15°, 20°, 25° (switch selectable, displayed on high-brightness 4-digit LED)
Bending distance 6 – 95 mm, accuracy ±0.1 mm (10 selectable spans)
Number of experiments Bi-directional force 20 times
Net weight 10 kg
Overall dimensions (L × W × H) 300 × 240 × 240 mm
Standards GB15811. GB18457. ISO 9626
Control & Display 5.7-inch LCD touch menu (120 × 90 mm)
Upgrade Free perpetual upgrade according to national standards
Power supply AC 220 V, 50 Hz
Part List Host (1 set), Printing paper (1 roll), Fixture (1 set), Weight (1 set), Operating Instructions

Accessories

(1) Printing paper (1 roll)

(2) Needle fixture (1 set)

(3) Weight set for bending calibration

(4) Operating instructions in English/Chinese

Maintenance Information

(1) Keep the device clean and dry; wipe with a soft cloth after use.

(2) Check the calibration of bending angles and LED display periodically.

(3) Avoid impact or vibration to ensure precise mechanical performance.

(4) Follow local electrical safety standards for power supply and grounding.
