Anchoring force guide pin device
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
The device is designed to meet the following standards:
(1) YY/T 0880-2013: Disposable Breast Positioning Wire and Guide Needle (China)
Optional international reference standards for extended compliance:
(2) ISO 10555-1: Sterile single-use intravascular catheters – General requirements
(3) ASTM F2084: Mechanical testing for medical guidewires
Features
(1) Accurately measures anchoring force to ensure clinical reliability.
(2) High-precision force sensor with hardware and software protection.
(3) Adjustable test speed and distance for flexible simulation.
(4) Built-in printer for immediate recording of test results.
(5) USB connectivity for data storage and export.
(6) Durable fixture made of high-quality 304 stainless steel.
(7) Simple operation with real-time force monitoring.
Parameters
| Parameter | Specification |
|---|---|
| Tensile force range | 0 – 20 N, accuracy ±1%, resolution 0.01 N |
| Test time | 1 – 999 s, error ±0.5 s |
| Test speed | 10 mm/min, 50 mm/min, 100 mm/min |
| Distance adjustment | 10 – 50 mm, adjustable |
| Force sensor | High-precision, with hardware/software protection |
| Fixture | 304 stainless steel |
| Force measuring mechanism | Built-in |
| Printer | On-board micro printer |
| Data storage | USB compatible, export to computer |
| Machine power | 70 W |
| Power supply | AC 90–240 V, 50 Hz |
Accessories
(1) Main test unit – 1 set
(2) USB storage device – 1 set
(3) Micro printer paper – 1 roll
(4) Operation manual – 1 set
(5) Optional fixtures/adapters for different guide needle diameters
Test Procedures
(1) Secure the guide needle or positioning wire into the stainless steel fixture.
(2) Adjust the test distance according to the sample size.
(3) Set the desired test speed and duration.
(4) Start the test; the instrument applies tensile force to the guide needle.
(5) Monitor the anchoring force in real-time.
(6) Test results are automatically recorded via the built-in printer and can be exported via USB.
Maintenance Information
(1) Keep the fixture, sensors, and printer clean and free of debris.
(2) Regularly calibrate the force sensor to ensure measurement accuracy.
(3) Avoid exposure to excessive moisture or vibration.
(4) Inspect mechanical components periodically for wear or loosening.
(5) Follow electrical safety standards during operation.
在线联系供应商
Other supplier products
 |
Elastic Tape Fatigue Testing Machine | This instrument is used to test the elasticity of elastic belt after reciprocating movement. Application Elastic Tape Fatigue Testing Machineis u... |
 |
High-Performance Contamination Resistance Equipment | Whats/App: +86 156 1874 6768 Web: standard-groups.com Standards You can operate this tester in compliance with the following standards: ISO 238... |
 |
