Scorch Tester Sublimation fastness tester
In the daily process of shaping and high temperature ironing, dyes heat stability will affect the appearance of fabrics.. Dyes heating , heat transfer properties will cause the change of fabric color.
Sublimation fastness tester (large) is used to determine the hot pressing ironing and dry heat (sublimation) color fastness properties for all kinds of dyed printing material and fabrics, it also can be used for determination the resistance to chlorine damage, textile bleaching products, scorch yellowing test, disperse dye sublimation fastness test, dye fastness test, high temperature dimensional stability. It is commonly used in printing and dyeing fabrics, textile auxiliaries clothing industry.
Standard
GB/T 5718.GB/T 6152.JIS L0879.JIS L0850.ISO 105 P01.ISO 105 X11.AATCC 117.AATCC 133. AATCC 92(G247)，AATCC 114(G247)，M&S C13(G247B)，M&S C10(G247B)
Features
Single work station easy for operation, high cost performance, Multi work station type can raise the efficiency and also meet M&S standard.
Upper and lower heat board control temperature separately , accurate temperature control, timing alert, control testing time exactly.
Heating board distance is adjustable, suitable for specimen of different thickness, High efficient insulation material ensures the safety operation.
Technical Parameters
| Parameters | G247 | G247B |
| Heating board area | 100mm×40mm | 210mm×210mm |
| Heating board material | Aluminumplate | Aluminumplate |
| Pressure | 4kPa±1kPa | 4kPa±1kPa（Fullarea） |
| Temperature heating range | Roomtemp.-300°C | Roomtemp.-300°C |
| Temperature control stability | ±1°C | ±1°C |
| Test Application | Hotpress,dryheat,chlorinedamage | Hotpress,dryheat,dimensionstability |
| Size | W250×D300×H230mm | W345×D520×H320mm |
| Weight | 9kg | 12kg |
