Strength Tester for Lead - end of Photovoltaic Modules
Standard
- IEC 61215-2:2016: Terrestrial Photovoltaic (PV) Modules – Test Requirements for Electrical and Mechanical Components
- CE Certification(Conformité Européenne)
Product Advantages
- IEC 61215-2 Compliance
- 2,000mm × 1,000mm Test Area: Accommodates full-size 72-cell modules and custom formats.
- ≤3% Measurement Accuracy: Ensures pass/fail determination per IEC’s tensile load requirements.
- Ultra-Precise Control
- 0.1N Force Resolution: Captures micro-fractures before catastrophic failure.
- Auto-Tare System: Compensates for fixture weight during low-force testing.
- Automated Testing
- Programmable Load Profiles: Simulates 10+ years of thermal cycling in 1,000 cycles.
- AI-Powered Failure Detection: Real-time IV curve correlation for connector degradation.
- Safety First
- Emergency Shutoff: Dual redundant safety circuits with load cell override.
- Overload Protection: 5 kN max force cutoff for delicate junction boxes.
- Modular Design
- Quick-Change Fixtures: Adapts to MC4, H4, and custom PV connectors.
- Expandable Test Area: Custom sizes up to 3.0m × 2.0m for large-format modules.
Product Features
- Motorized Tensile Stage: 0–500 mm/min adjustable speed with force-displacement graphing.
- 7” Touchscreen HMI: Preloaded IEC 61215-2 test sequences with auto-hold functions.
- Dynamic Force Feedback: 0.1N resolution load cell with peak force memory.
- Self-Calibrating System: Auto-linearity checks before each test.
- Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Area | 2,000mm (W) × 1,000mm (D) (customizable) |
| Force Range | 0–5,000N (5 kN capacity) |
| Force Resolution | 0.1N (10 gf) |
| Speed Accuracy | ±1% of setpoint |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 2,200mm (W) × 1,200mm (D) × 1,800mm (H) |
| Weight | 250 kg (net) |
Accessories Included
- Testing Kit:
- 10x PV Connector Fixtures (MC4/H4 compatible).
- 5x Calibration Grade Load Cells (10N–5,000N).
- Software Suite:
- License key forTensileTest Pro(Windows/Linux).
- 1-year free access to cloud-based fatigue analysis tools.
- Calibration & Safety:
- NIST-traceable force gauge.
- Insulated gloves (Class 0, 3 pairs).
- Maintenance Kit:
- Spare drive belts and bearings.
- Machine cleaning solution (non-corrosive).
- Documentation:
- Multilingual quick-start guide (printed + digital).
- Compliance certificates for IEC/UL/ISO standards.
