Hydraulic Oil Filtration and Dewatering Tester

Applications:

Hydraulic and lubrication system oil purification and filtration;

Hydraulic and lubrication system oil degassing;

Hydraulic and lubrication system oil demulsification;

Hydraulic and lubrication system oil dewatering.

Technical parameters:

1. Rated flow rate L/min: 40. 100. 150

2. Rated pressure MPa: 0.6

3. Original pressure loss MPa: ≤0.2

4. Coarse filtration precision μm: 100

5.Primary filtration precision μm: 25. 40

6. Secondary filtration precision μm: 3. 5. 10

7. Motor power Kw: 1.1+0.75. 2.2+1.1. 4+1.1

8.Voltage V: 380

9. Weight Kg: 380. 480. 680

10. External dimensions mmLXBXH: 1500×800×1700. 1800×1000×1800. 2200×1100×180

Technical features:

1. the oil filter includes two motor-driven special gear pumps, with low noise, self-absorption capacity, smooth operation and other characteristics;

2. high-pressure pipeline is equipped with an overflow protection device, which can effectively protect the hydraulic system's Safety;

3. the use of thermal relay protection to prevent motor damage caused by motor overload;

4. suction port coarse filter to protect the oil pump and extend the service life of the fine filter;. 5. the pump is equipped with a two-stage fine filter after the pump to protect the oil pump.

5. Two-stage fine filter is provided after the pump, so that the oil can quickly reach high cleanliness and achieve the required result;

6. The fine filter can be selected with different precision according to the different needs of users to achieve the required result;

7. The panel is equipped with a pressure gauge, which continuously indicates the operating status of the system and the degree of contamination of the filter element during the working time;

8. The adoption of a separate heating system can effectively solve the impact on the life of the filter element in case of a low ambient temperature. The influence on the life of the filter element is effectively solved in the case of low ambient temperature.

Other supplier products

	Mask Synthetic Blood Penetration Tester	Medical masks synthetic blood penetration tester is used to determine the resistance of medical protective masks to penetration by synthetic blood ...
	Medical Mask Differential Pressure Tester	Standards: YY 0469-2011 YY/T0969-2013 EN 14683:2014 Annex C ASTM F2100 Applications: Medical Mask Differential Pressure Tester also called...
	Photovoltaic module backplane peeling strength testing machine/ Peel strength testing machine for pv/ Solar panel backsheet adhesion tester	Introduction: The Photovoltaic Module Backplane Peeling Strength Testing Machine is a specialized device designed to evaluate the peeling strength...
	Battery Slurry Resistance Tester	Standard ASTM B193: Standard Test Method for Resistivity of Electrical Conductor Materials ISO 18516: Conductive Coatings – Measurement of ...
	Pump and Valve Contamination Tolerance Tester	Meet the standard: ISO 4406 ISO 18413 ISO 10707 ISO 6403 ISO 10372 NFPA T2.6.1 Product Introduction: Solid particle contamination is a major...
