Xenon Light Fastness Test Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1.Full-Spectrum Xenon Lamp
Xenon arc lamps emit a continuous spectrum from UV to visible and infrared, closely simulating natural sunlight.Water-cooled xenon lamps ensure stable operation for over 1600 hours.
2.Accurate Environmental Simulation
Temperature is controlled from ambient to 100°C, while humidity can be adjusted between 50%RH and 98%RH. A built-in water spray system simulates rain to evaluate water resistance and color fastness.
3. Customizable Optical Filters
A variety of filter options are available, including Daylight Q, Daylight B/B, Window Q, and Window B/B. Each filter allows specific wavelengths to pass through.
4. Flexible Sample Holder Designs
LIB offers multiple holder configurations—flat shelf and rotating drum types—to accommodate various sample shapes, sizes, and test requirements.
Specifications
Model |
STD XL-S-750 |
Internal Dimension (mm) |
950*950*850 mm |
Overall Dimension (mm) |
1400*1400*1950 mm |
Chamber Type |
Rotating Holder Holds42 Samples with a Size of 95mm*200mm |
Irradiation Source |
1 piece of 4500w water-cooled xenon arc lamp |
Irradiance Range |
35~150 W/㎡ |
Bandwidth Measurement |
300nm~400nm (340nm or 420nm) |
Chamber Temperature Range |
Ambient～100 ℃ ±2℃ |
Black Panel Temperature |
BPT 35～85 ℃ ±2℃ |
Humidity Range |
50% ~ 98% RH |
Humidity Deviation |
± 5% RH |
Water Spray Cycle |
1~9999H59M (Adjustable) |
Controller |
Programmable color LCD touch screen controller |
Radiometer |
UV Radiometer, Tolerance: ±5% |
Cooling System |
Mechanical compression refrigeration system |
