Carpet Pilling and Fuzzing Tester
Instrument Description
This instrument is used to simulate the pilling and fuzzing phenomena that occur during the normal use of carpets. The instrument contains a roller covered with nylon, which can generate a frictional motion with a set number of cycles on the surface fibers of the sample. Then, observe the appearance changes of the sample.
Relevant Standards
GB/T21196 - 2007. GB/T4802.2. GB/T13775. FZ/T20020. ASTM D4970. ISO12945 - 2. ASTM D4966. ASTM D3886. ISO12947. JIS L1096. IWS TM196. TM112. M&S
Application Scope
It is used for performance tests of abrasion resistance, wear - and - tear, and appearance changes (pilling) of textiles and membrane materials.
Working Principle
The circular textile sample rubs against the standard abrasive along the motion trajectory of the Lissajous curve under a certain pressure, resulting in sample damage. The abrasion - resistant performance of the textile is represented by the number of abrasion cycles until the sample is damaged.
Parameters
Rollerdimensions:Ø63mm×60mmwide
Rollermass:2.0±0.1lb(0.91±0.05kg)
Reciprocatingstroke:150±5mm
Reciprocatingfrequency:60±2cyclesmin⁻¹
Testcycles:selectable1–9,999(commonly1,000cycles)
Samplesize:min.180mm×180mm
Maximumsamplethickness:25mm
Workingarea(testbed):220mm×220mm
