Rubber low temperature brittleness machine - Impact & Durability
Product Introduction:
Plastic low temperature embrittlement testing machine is to determine the temperature of rubber and plastic when the sample is damaged by impact under specified conditions, that is, the brittleness temperature, which can make comparative identification of the performance of non-rigid plastics and other elastic materials under low temperature conditions, and the advantages and shortcomings of temperature and low temperature performance. Therefore, both in scientific research materials and production process control are indispensable. This instrument is according toGB/T 15256andGB/T5470standard design, the development of compressor refrigeration equipment. The equipment adopts the cascade compressor refrigeration technology, the heat balance principle and the circulation stirring method to achieve automatic uniform cooling and constant temperature of the sample. This equipment is divided into rubber low temperature brittleness testing machine and plastic low temperature brittleness testing machine two kinds.
Standards：
1. ISO812 Rubber, vulcanized or thermoplastic - Determination of low-temperature brittleness
2. GB/T 15256 Rubber, vulcanized or thermoplastic - Determination of low-temperature brittleness
3. JIS-K-6261-2006 Rubber, vulcanized or thermoplastic - Determination of low temperature properties
4. ASTM D2137 Rubber property-Brittleness point of flexible polymers and coated fabrics
Technical parameter:
1. Temperature control range: -80℃ (room temperature ≤25℃) (there are -60. -70. -80℃ three models for customers to choose)
2. Cooling speed:
0 ℃ —— 1.2 ℃ —— 20 ℃ / min
- 20 ℃ —— 1.0 ℃ to 30 ℃ / min
- 30 ℃ —— 0.7 ℃ to 60 ℃ / min
-40℃——-60℃ about 0.7℃/min
-60℃——-80℃ About 0.5℃/min
Note: The use environment is used at room temperature (23-25 ℃)， and the effect of diffusing temperature of the compressor is maintained during work. The side door can be fully opened.
3. After constant temperature, the temperature fluctuation within 3 minutes of the test: < ±0.5℃
4. Overall size: 900×505×800mm (length × width × height)
5. The overall size of the studio: 220×170×70mm (length × width × height)
6. Cooling medium: ethanol or other non-freezing liquid
7. Mixing motor: 15W
8. Working power supply 220V——240V,50Hz,2kW
