Fully Automatic AC/DC High - Voltage Tester for Wires and Cables
Standards
- ISO 14572. IEC 60529: International standards for wire insulation integrity and environmental testing.
- UL 2556. CSA C22.2: North American safety requirements for wire and cable testing.
- GB/T 3048. GB/T 18384: Chinese national standards for electrical performance and EV safety.
- Equivalent Standards: VDE, ASTM D495. SAE J1678. and automotive OEM-specific protocols.
Main Parameters:
1. Input voltage: 220V/50HZ
2. Power: 5KVA
3. Output voltage: 0.00～50.000KV
4. Breakdown current: Can be arbitrarily set within the range of 1.0~100.0mA
5. Voltage - rising speed: Can be arbitrarily set within the range of 100V~5000V/S
6. Accuracy: Class 1.0
7. Test time: Can be arbitrarily set within the range of 0.00~999.9H/M
8. Dimensions of the control console: 800 X 800 X 1300mm, dimensions of the high - voltage transformer: 500 X 500 X 1000mm
9. Weight: 150KG
