Apparel Drying Dynamics Control System
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Textile Drying Time Tester is a precision instrument designed to measure evaporation rate and drying time of textiles under controlled environmental conditions. It evaluates moisture absorption, drying efficiency, and fabric resilience, essential for quality assurance, R&D, and product development in textile manufacturing.
Type: Environmental testing chamber with humidity and temperature control
Standards
ISO 11092 – Textile evaporative resistance
ASTM D737 – Air permeability and drying correlation
AATCC 195 – Moisture management properties
GB/T 12704-2019 – Chinese textile drying standard
Features
(1) Multi-Test Modes: Static drying, dynamic drying simulating body movement, and rain simulation for waterproof fabrics.
(2) Advanced Monitoring: Real-time moisture mapping using thermal imaging; AI-based drying prediction model.
(3) Automation: Auto-reset system after each test; motorized humidity control; self-cleaning condensate drainage.
(4) Batch Analysis: Compare multiple samples, export data in Excel or PDF.
(5) User-Friendly Operation: Touchscreen interface, programmable test cycles, and automated reporting.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | 20°C–60°C (±0.5°C accuracy) |
| Humidity Control | 30%–90% RH (programmable) |
| Drying Mechanism | Airflow circulation (0.5–2.5 m/s) + infrared heating |
| Moisture Detection | Capacitive moisture sensor (±0.1% accuracy) |
| Sample Size | Up to 500×500 mm (adjustable clamping frame) |
| Power Supply | 220V/50Hz, 1.8 kW |
| Dimensions | 1200×800×1500 mm (L×W×H) |
Accessories
Adjustable clamping frame for specimens
Water spray module for rain simulation
Data acquisition software for drying curves
Thermal imaging camera (optional)
Test Procedures
Sample Preparation: Cut specimens to 100×100 mm.
Calibration: Validate system with reference samples.
Testing: Start the cycle with predefined temperature and humidity.
Analysis: Generate drying curve and moisture loss graph.
Cleaning: Auto-drain condensate reservoir after testing.
Maintenance Information
Avoid contact with heated surfaces during operation and maintenance.
Ensure power supply is properly grounded.
Keep at least 50 cm clearance from airflow vents.
Regularly check moisture sensor calibration and clean condensate drainage.
Inspect airflow fans and heating elements periodically to maintain uniform drying conditions.
