Automotive interior fogging tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard Test
DIN 75201: Automotive trim material fogging resistance.
ISO 6452: Coated fabrics fogging behavior in vehicle interiors.
SAE J1756: Automotive interior material fogging test protocol.
BS EN 14288 & QB/T 2728: Leather and textile fogging evaluation.
PV 3920/3015: VDA-standard fog value determination for non-metallic materials.
ES-X83231. NES M0161. GM 9305P: OEM-specific fogging requirements for automotive suppliers.
Feature
Dual-Bath System:
High-Temperature Bath: 670×490×540mm, 3kW heating power (up to 150°C).
Low-Temperature Bath: 400×220×520mm, 500W cooling capacity (0–100°C).
Automated Controls:
Digital thermoregulator with microprocessor for precise temperature programming.
Programmable timer (1–9999 min) with auto-stop and end-test buzzer.
Modular Accessories:
18/8 stainless steel test cups, flat beakers, and chrome steel rings for sample mounting.
Six interchangeable cooling plates and haze/gloss measurement kits.
Safety Compliance:
CE-certified with anti-acid epoxy coating, emergency stop, and overpressure relief.
Parameters
| Parameter | Specification |
|---|---|
| High-Temperature Range | Room temperature – 150°C (280°C optional) |
| Low-Temperature Range | 0–100°C |
| Temperature Stability | ±0.1°C (at 200°C) |
| Heat-Up Time | <45 min (to 150°C) |
| Cooling Capacity | 500W (low bath) |
| Power Supply | AC 220V, 50Hz, 3.5kW |
| Dimensions | 500 (W) × 650 (D) × 600 (H) mm |
| Net Weight | 50 kg (excluding thermal media) |
| Data Interface | USB 2.0. remote sensor compatibility |
| Safety Systems | Magnetic switch, thermostat, audible alerts |
Accessoriess
Standard accessories：Main unit *1. constant temperature controller (cooling device) *1. glass beakers (fogging cups) *6.circular glass plates *6. square glass plates *6 (for reflection method testing), haze meter *1. metal rings *6.Fluororubber sealing rings *6. aluminum foil *1 pack, φ80mm sampler *1. dioctyl phthalate (DOP), silicone oil (heat transfer oil) / 32Kg, diisodecyl phthalate (DIDP)
Test Procedures
1.First of all , get the accessories and test samp.
2.Prepare an aluminum foil,place it in the scale to weigh it, and record the value.
3.Place aluminum foil and glass plate over the fog cup.
4.Set the cycle parameters of the low temperature control box, set host temperature and time parameters.
5.Start the instrument,the sample is heated inithe fog cup.
is started.When the timing is reached, remove.
the aluminum paper fZrom the station.
6.Put it into the scale again and weigh it, and record the value.
