G631A electric shoe stripping testing machine

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Product Introduction:

Upper peeling strength tester is suitable for testing the peeling strength between the sole and the upper of the shoe, the principle is to load the shoe on the shoe last clamp on the machine, peel the sole and the upper joint with the peeling knife, measure the force required when stripping force is the peeling force, and then calculate the peeling strength according to the peeling force and the width of the knife edge.

Reference standard:

GB/T 15107-2013, GB/T 3903.3-2011, BS 20344, QB/T 4329-2012, QB/T 1002-2015.6.5 and other standards

Technical parameters:

1, Peeling force: 1000N

2, peeling knife width: 20±0.2mm and 10±0.1mm

3, peeling knife edge down speed: 20±2mm/min, rise and fall speed is adjustable

4, positioning rod and tie rod spacing: 50——70mm adjustable

5, dial gauge: 0.001—— 10mm, accuracy: 0.001

6, the average lifting range: 40mm

7, volume (approx.) : 560×320×750mm

8, Power supply: 1∮, AC220V, 50HZ

9, Weight (approx.) : 45kg
