Weatherometer Laboratory Testing Equipment(UV)
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1. UVA-340. UVB-313 and other UV lamps, a single power of 40 watts, can accurately control the irradiation intensity of 0.15-5W/m².
2. The inner wall material of SUS304 can resist the erosion caused by uv accelerated aging test.
3. The shelf Weatherometer Laboratory Testing Equipment(UV) can meet the special-shaped test parts, and the requirements for the test parts are less.
4. The work room is equipped with a blackboard to accurately control the light intensity and the temperature of the workroom.
Specifications
|
Model |
UV-660 |
|
Internal Dimension (mm) |
450*1170*500 |
|
Overall Dimension (mm) |
610*1330*1470 |
|
Irradiation Source |
Fluorescent UV lamps (8) - 40 W |
|
Temperature Range |
Ambient～90 ℃ ±2℃ |
|
Black Panel Temperature (BPT) |
35～80 ℃ |
|
Humidity Range |
≥95% RH |
|
Bandwidth |
290 ~ 400nm |
|
Irradiance Control |
0.3~20 W/㎡ |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
|
Water Supply System |
Automatic water supply, Water purification system |
|
Safety Device |
Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
|
Exterior Material |
Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
