Automatic Cross-hatch Tester
Product Introduction:
It is a general purpose instrument used to perform a variety of different scratch and scratch resistance tests on paint layers and plastic surfaces. For test plates of different thickness, parallel and cross cutting can be performed with single and multi-row cutting knives. In particular, the adhesion test is carried out according to the cross marking method for all user standards, and the scratch resistance test is carried out according to the GME60 280. A wide range of test parameters and a wide selection of test tools make these tests easy to perform.
Meet the standard:
GM 14688(Method A)， GM 14688(Method B)
PV 3952 public standard, GB 9286-2021
Q/SQR S1-16-2016 Chery standard
Q/SQR T1-64 Chery standard, GME 60 280
GB/T 9286-97/IS0 2409IS02409
GB/T 9279-2007/IS0 1518:1992
QCC SY051-2012
Technical parameters:
Control system: PLC
Size of the test piece (relatively small) : 80x50mm
Sample thickness: 0.5-20mm
Marking path: 0-45mm
Operation interface: Simplified Chinese/English
Size of the test piece (relatively large) : 105mm wide, arbitrary length
Standard load range: 2-50N
Dimensions (W x H x D) : 380x480x760mm
Power supply: 115/230VAC, 50/60Hz(please specify voltage when ordering)
Operation interface: Color 7 inch touch screen, English and Chinese switching, no less than two kinds of voice
