Anti-glare Panel Falling Weight Tester
Meet the standard
GB/T24718-2023，GB/T 24718-2009，JTG/T D33-2012
Scope of application
The anti-glare board impact testing machine is designed and produced for each testing unit to measure the impact resistance of the anti-glare board, which is suitable for plastics, plastic products ceramics, glass fiber, tempered glass and other materials and test the hardness of coatings.
Instrument features
With a sample holding device, to prevent inaccurate results caused by random sample projectiles;
With protective protection plate, to prevent the ball from secondary collision with the sample and the ball bounce injury;
Double overshoot protection, the overshoot motor automatically stops, need to be manually lifted to prevent damage to the instrument and protect the user;
Program with automatic memory function, power off or unplug, is still the memory setting before power off;
Motor with holding brake function, the arm will not slide down in the case of power failure;
Laser rangefinder ranging, ranging accuracy;
Two modes of operation, namely automatic and manual two ways;
Low-voltage components such as: brand buttons, relays, AC contactors, etc., stable performance, safe and reliable;
Easy to install, easy to operate, long service life.
Standard configuration
1. One host
2. 1 standard iron ball
3. One national standard power cable
4. Product packing list 1 copy
5. 1 copy of product manual
6. One copy of product certificate
Technical parameters
Electromagnet suction 50kg
The steel ball weighs 1kg±10g
Steel ball diameter 63mm
Cantilever extension length 350mm(310mm from the center of the ball)
Cantilever lifting stroke 300mm(i.e. impact height can be adjusted at 900-1200)
Laser sensor measurement accuracy 1mm
The laser sensor has an error of 5 parts per thousand
Laser spot 0.5-1mm
The diameter of the anti-secondary impact partition is 65mm, and the height is adjustable from 20-110mm
Weight 130kg
