MST clothing pressure tester-QINSUN
Product Introduction
The MST Clothing Pressure Tester/Underwear Pressure tester is used in the body or
in the laboratory to easily measure the pressure of elastic bandages and clothing in
medicine, sports, fashion and other fields.
Starting with the MST Mark V version, software updates are available for additional
features. MST Mark III and later, MPT-4. and MPT-7 can also be connected without a
software update.
Compliant standards
ENV 12718.CEN/TR 15831.RAL-GZ 387/1.RAL-GZ 387/2.FZ/T 73031.YY/T 0851.YY/T 0853
Scope of application
1. Foot, knee, elbow bandages, etc.;
2. Scarves, sleeves, tubes, tights, leggings, sweatpants, belly belts, back supports;
3. Functional underwear, sports bra, compression shirt, cycling shorts, shapewear;
4. Full body sportswear, space suit, hospital protective suit, rescue suit, military
uniform, military uniform, etc.
The MPT-4 has four multipoint probes and can also be directly connected to all older
MST Mark X versions.
The MPT-7 has seven multipoint probes and is recommended for use with MST Mark
V devices. The MPT-7 can only operate to a limited degree on the older MST Mark X
versions because they only have six measuring points.
Main parameter
Multi-point probe:
1. Diameter :50 mm;
2. Tube length :1000 mm;
3. Maximum pressure :80 mm Hg or 10.6 kpa;
4. Measuring range :55-70 mm Hg or 0.7-9.3 kpa;
5. Features: waterproof, washable, sterilizable.
Electrical connection data:
1. Input voltage range :100-240VAC;
2. Input frequency :50-60 Hz;
3. Power consumption :35 watts.
