Battery combustion tester
Equipment introduction
Battery combustion tester used for battery fire resistance, battery combustion
injection test. The battery combustion testing machine is to fix the screen at 38.1mm
above the top of the burner, the screen has 20 holes every 25.4mm, the steel wire
diameter is 0.43mm, ignite the burner, and observe the battery burning until the
battery explodes or the battery burns, and time the combustion process.
Meet the standard
UL2272-2016, UL2271-2013, GB/T31241-2014, GB/T18287-2013, GBT 8894.4-2008,
YD/T 2344.1-2011, GB/T31485-2015, etc.
Technical parameter
1. Burner: Bunsen burner, the inner diameter of the tube is 9.5mm, the length is
about 100 mm
2. Flame application time :0-999.9 s 0.1 s
3. Test round hole surface diameter :102mm
4.Test mesh screen: A mesh screen consisting of 0.43mm(0.017inch) diameter
stainless steel wire woven with 20 mesh per US inch
5. Flame distance from screen height :38mm
6. Octagonal net cover width: the distance between each side is 24 "（610mm），
octagonal, and the eight sides are movable for easy replacement and disassembly
7. Octagonal net cover height :12 "（305mm）
8. Octagonal cover material: aluminum mesh, consisting of 0.010inch（0.25mm）
diameter of aluminum wire woven into a net containing 16-18 mesh per inch
9. Protective box size: about 730x740x500mm
10. Box material: inner box stainless steel, high temperature resistance,
insulation, corrosion resistance, outer box cold rolled steel paint treatment
11. Visual observation window :150x150mm, multi-layer tempered glass and
equipped with stainless steel mesh
12. Ventilation: The rear side of the box has a fan and ventilation inside the box
13. Combustion gas: methane or LPG （customer's own）
14. Power supply :AC220V, 50Hz
15. Equipment weight: about 100kg
