Carpet Abrasion Resistance Tester

Standard

  • ASTM D4157(Standard Test Method for Abrasion Resistance of Textile Fabrics (Oscillatory Cylinder Method))
  • ISO 12947-2(Textiles - Determination of Abrasion Resistance - Part 2: Martindale Method)
  • EN 14465(Resistance to Abrasion for Carpets)

Product Advantages

  1. Unmatched Precision
    • High-resolution load sensor (±0.1N accuracy) and programmable test cycles deliver repeatable results for wool, synthetic, and blended carpets.
  2. Adaptive Testing Modes
    • Supportsrotary(ASTM D4157) andplanar(ISO 12947) abrasion methods to replicate light residential use to heavy commercial traffic.
  3. User-Centric Design
    • 7-inch touchscreen control panel with multilingual support (English, German, Spanish, Chinese) and real-time data visualization.
  4. Industrial-Grade Durability
    • Stainless steel test chamber, corrosion-resistant components, and anti-vibration feet ensure long-term reliability in busy labs.
  5. Cost-Efficient Maintenance
    • Modular design allows easy replacement of abrasive heads and clamps, minimizing downtime and operational costs.

Product Features

  • Customizable Testing Parameters:
    • Adjustable test speed (10–120 rpm) and load pressure (1–50 N) to simulate everything from bare feet to heavy furniture movement.
    • Automatic cycle counter with pause/resume function for uninterrupted workflows.
  • Safety & Compliance:
    • Emergency stop button, over-temperature protection, and CE/UL certification for safe operation.
  • Data Management:
    • Onboard memory stores 10,000+ test results, exportable via USB/Bluetooth in CSV/PDF formats. Compatible with LIMS (Laboratory Information Management Systems).
  • Universal Sample Compatibility:
    • Adjustable clamps accommodate carpets up to 500mm in diameter (rotary mode) or 300×300mm (planar mode).

Technical Parameters

ParameterSpecification
Test Speed Range 10–120 rpm (±1 rpm accuracy)
Load Capacity 1–50 N (adjustable in 0.1N increments)
Sample Size (Rotary) Up to 500mm diameter
Sample Size (Planar) 300×300mm
Abrasive Head Diameter 150mm (standard Martindale H-18)
Power Supply 100–240V AC, 50/60Hz, 300W
Dimensions (L×W×H) 600×500×800 mm
Weight 90 kg
Operating Environment 15–35°C, ≤85% RH (non-condensing)

Accessories Included

  1. Abrasive Heads(2 pcs): Standard H-18 (planar) and CS-17 (rotary) for versatile testing.
  2. Sample Clamps(3 sets): For loop-pile, shag, and flat-weave carpets.
  3. Dust Cover: Transparent acrylic shield for operator safety.
  4. Calibration Kit: Weight set and gauge for annual equipment verification.
  5. User Manual & Software: Digital guide (multilingual) + PC software for advanced data analytics and ISO-compliant report generation.

Ideal For:

  • Carpet manufacturers (residential, commercial, hospitality)
  • Textile testing laboratories
  • Flooring retailers requiring durability certifications
  • Architectural firms specifying high-traffic carpets
