Solar module framing machine
Model Name GSFM-2011
Maximum group-frame outside dimensions(four squares) 2000×1100×（35～50）mm
Minimum group-frame outside dimensions(four squares) 350×350×（35～50）mm
Framing precision The tolerance of the oppose sides: ±1mm
Diagonal size of the difference ±1.5mm
Air pressure 0.4Mpa~0.7Mpa
Hydraulic pressure 1.0Mpa~15.0Mpa
Angular deviation of four square ±0.5°
Power of the group frame Aerodynamic Hydraulic power
Outside dimensions 2900mm×1900mm×970mm
Control model Manual
Weight 1200kg
