Friction and wear testing machine
Standards
ASTM G99-04
ASTM G77-16
ISO 9352:1995
GB/T 12444-2006
GB/T 12607-2007
GB/T 1865-2009
Application field
Petrochemical: Used to assess the long-term wear resistance of lubricating oil and grease, and to develop a variety of high-grade series of hydraulic oil, internal combustion engine oil, gear oil and other products.
Materials science: Helps researchers understand the friction and wear properties of emerging materials, providing important data support for the design and optimization of new materials.
Universities and institutes: as an important tool for teaching and research, it is used for research and exploration in the field of tribology.
Industrial field: such as subway, automobile, train, wind power, ship, construction machinery, etc., used to evaluate the friction and wear performance of various parts.
Technical Parameters
Working range of test force: 10~1000N stepless adjustable.
Relative error of test force: ±1%.
Measuring range of friction torque: 0~2500N.mm
Relative error of friction torque: ±2
Spindle speed range: 1~2000r/min
Maximum output torque of main motor: 5N.m
Test medium: oil, water, mud, abrasive, etc.
Temperature control range: room temperature~260°C
Maximum distance between the main shaft of the tester and the lower sub-disk: >75mm
Test time control range: 1s~999999min.
