Multiphase High - temperature and High - pressure Explosion Limit Tester
Reference Standards:
EN 1839 ASTM E918 ASTM E2079 EN 15967 UL9540A
Product Features:
1. Designed with a modular concept to flexibly meet various testing requirements.
2. Allows for free editing of the experimental process to cater to different testing needs.
3. The testing container is made of 316L stainless - steel, which is corrosion - resistant.
4. It adopts a jacket temperature - control method, featuring high temperature - control efficiency.
5. The constant - temperature conditions can be flexibly set, balancing efficiency and accuracy.
6. Equipped with a high - efficiency vacuum pump, and the cleaning parameters can be set to fully eliminate residual effects.
7. With a precision measurement and control system and a compensation gas - mixing algorithm, it enables precise control of gas concentration.
8. It has a stirring function to ensure the uniformity of the mixed gas.
9. It uses a pressure sensor specially designed for explosions, which can work at high temperatures and has good dynamic performance.
10. Automatic control of gas samples, including automatic vacuum - pumping, automatic gas - mixing, and automatic stirring. 11. The equipment has a safety interlock function to enhance safety.
12. Multiple safety protections such as safety valves and burst discs effectively ensure the safety of experimenters.
Technical parameters:
|
Operating Environment |
(-5 to 45)°C, <95%RH |
|
Test Vessel Temperature Control Range |
Room temperature to 200°C |
|
Configuration Gas Maximum Pressure |
Supports one atmosphere, ±0.1%FS |
|
Test Vessel Design Pressure |
≥2.0MPa |
|
Explosive Pressure Sensor |
≥5.0MPa, linear ±1.0%FS |
|
Explosive Pressure Acquisition System Sampling Frequency |
≥5kHz |
|
Explosive Pressure Acquisition System Single Experiment Data |
≥10.000 cycles |
|
Gas Input Channel |
3 channels |
|
Maximum Stirrer Speed |
400rpm, speed adjustable |
