Thermal Insulation Material Bond Strength Tester

Product Introduction:

High-precision rivet drawing instrument products adopt S-type high-precision sensor, mechatronics design, a complete set of instruments

As a whole, the handle, S-type sensor, lead screw, reaction seat mechanical part constitutes a "door" is a structure, digital display table, can

Read tensile value (kN) and strength value (Mpa), automatic calculation, peak retention, storage and query function, especially suitable

For laboratory and field use, the full set of detector has the characteristics of powerful function, light weight, labor-saving handle operation and simple.

Technical parameters:

Product model: ZHJM-6A

Instrument structure: integrated

Display mode: Force value KN/Strength value Mpa adjustable

Measuring range: 0-6.000KN/3.75Mpa

Resolution: 0.001KN

Test accuracy: 0.5%F.S

Peak holding, LCD lighting: Yes

Data storage: 500

Value correction: 10 polylines

Power supply: high capacity lithium

Drawing stroke: 65mm

Theme material: Light alloy

Theme weight: 2.8Kg
