Xenon Fastness Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1. Adopts high-intensity xenon lamps with a spectral range of 300-400 nm, which can accurately simulate ultraviolet rays, visible light and infrared rays in natural sunlight, providing a realistic testing environment.
2. With an acceleration factor of 5 to 10 times, significantly shortens the testing time through strong light exposure, thereby quickly evaluating the performance of materials when exposed to sunlight and the environment for a long time
3. The temperature range is from RT to 100°C, and the humidity range is from 50% to 98% RH. It can simulate various climatic conditions and comprehensively assess the weather resistance of materials.
4. Test 42 samples simultaneously. The standard sample size is 95mm x 200mm, which improves the testing efficiency and meets the demand for a large number of samples
Specifications
Model |
STD XL-S-750 |
Internal Dimension (mm) |
950*950*850 mm |
Overall Dimension (mm) |
1400*1400*1950 mm |
Specimen Holder Size(mm) |
95*200 |
Specimen Capacity |
42pcs |
Chamber Type |
Rotating Holder |
Irradiation Source |
1 piece of 4500w water-cooled xenon arc lamp |
Irradiance Range |
35~150 W/㎡ |
Bandwidth Measurement |
300nm~400nm (340nm or 420nm) |
Chamber Temperature Range |
Ambient～100 ℃ ±2℃ |
Black Panel Temperature |
BPT 35～85 ℃ ±2℃ |
Humidity Range |
50% ~ 98% RH |
Humidity Deviation |
± 5% RH |
Water Spray Cycle |
1~9999H59M (Adjustable) |
Controller |
Programmable color LCD touch screen controller |
Water supply system |
Automatic water supply, Water purification system |
Radiometer |
UV Radiometer, Tolerance: ±5% |
Cooling System |
Mechanical compression refrigeration system |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
