ASTM G154 UV Accelerated Aging Chamber丨UV Accelerated Aging Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1.TheUV accelerated aging chamberuses fluorescent ultraviolet lamps to simulate the ultraviolet part of sunlight: the UVA340 lamp simulates the shortwave ultraviolet (295-365 nm). The UVB313 lamp provides stronger ultraviolet radiation for accelerated material aging testing.
2.The ASTM G154 UV accelerated aging chamber can simulate high or low temperature environments to evaluate the aging behavior of materials under different temperature conditions, temperature control range: ambient to 90℃±2℃.
3.Theworkroomis made of SUS304 stainless steel, which is corrosion-resistant and easy to clean, and can work under long-term high humidity and high intensity ultraviolet light.
4.In the UV aging environment simulated, the temperature, spray and irradiation intensity can be controlled. The irradiation meter tracks the irradiation amount in real time and sends it back to the controller.
Specifications
|
Model |
STD UV-SI-260 |
|
Internal Dimension (mm) |
450*1170*500 |
|
Overall Dimension (mm) |
610*1330*1470 |
|
Specimen Holder Size(mm) |
75*150 |
|
Specimen Capacity |
56 Pieces |
|
Irradiation Source |
Fluorescent UV lamps (8) - 40 W |
|
Temperature Range |
Ambient～90 ℃ ±2℃ |
|
Black Panel Temperature (BPT) |
35～80 ℃ |
|
Humidity Range |
≥95% RH |
|
Bandwidth |
290 ~ 400nm |
|
Irradiance Control |
0.3~20 W/㎡ |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Distance of Specimen and lamp |
50mm |
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
|
Water Supply System |
Automatic water supply, Water purification system |
|
Safety Device |
Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
|
Exterior Material |
Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
