small to medium sized tanks cleaning nozzles
High impact rotary tank cleaning nozzle
Model NO.: STD 4
Working Principle:
Impeller is driven by cleaning fluid and drives internal reduction mechanism.
The speed is constant to obtain greater impact when increasing pressure.
Features & Benefits:
Cleaning fluid is sprayed out as a water column at the nozzle, and the impact force is greater, with precise layout of ball of self -rotating tank cleaning head, to achieve 360° full coverage cleaning.Built-in deceleration structure, impeller drive, stable operation, constant speed, it takes 1-3 seconds for the ball head to rotate one circle
Operating pressure of 3-15bar
Application:
STD series rotary tank washer is suitable for small to medium sized tanks, such as dairy, food, pharmaceutical, beer, chemical, industrial fermentation industries and occasions that require high impact cleaning. Especially suitable for occasions with certain viscosity, such as syrup, powder, etc.
Soup kettles
Yeast propagation tanks
Batch processing vessels
Fluid bed dryers
Ink and paint mixing vats
Brew kettles
Storage tanks
Spray dryers
Commercial ovens
