Automotive connector insertion and withdrawal force testing machine
Standards
Designed to meet rigorous automotive industry standards, including ISO 5023. IEC 60512. and USB-IF specifications, our testing machine ensures accurate force measurement for connectors used in automotive infotainment systems, powertrains, and safety electronics. It validates durability under extreme conditions, helping manufacturers achieve compliance with OEM-specific requirements and international regulations.
Technical Parameters
| Parameter | Specification |
|---|---|
| Load Capacity | 50kg, 20kg, 10kg, 5kg (user-selectable) |
| Force Resolution | 0.01N |
| Stroke Range | 0–150mm (vertical) / 0–75mm (X/Y axis) |
| Positioning Accuracy | ±0.01mm (manual micro-adjustment) |
| Speed Control | 0–200 mm/min (programmable) |
| Motor System | Servo motor with ball screw transmission |
| Data Output | Real-time graphs, CSV/Excel export, PDF reports |
| Power Supply | 220V AC, 50/60Hz, 400W |
| Dimensions (WxDxH) | 600 x 550 x 1200 mm |
| Weight | 120 kg (net) |
