Protective Clothing Resistance Test device

Related Standards

GB/T 22042 - 2008 Clothing - Anti-static Performance - Test Method for Surface Resistivity

GB/T 22043 - 2008 Clothing - Anti-static Performance - Test Method for Resistance Through the Material (Vertical Resistance)

GB 12014 - 2009 Anti-static Clothing

GB/T 12703.4 - 2010 Textiles - Evaluation of Electrostatic Properties - Part 4: Resistivity

EN 1149 - 1 - 2006 Protective Clothing - Electrostatic Properties - Part 1: Surface Resistivity Test Method and Requirements

EN 1149 - 2 - 1997 Protective Clothing - Electrostatic Properties - Part 2: Resistance Through the Material - Vertical Resistance Test Method

AATCC 76 Fabric Surface Resistivity

ANSI / ESD STM2.1 Anti-static Clothing Resistance Test Method - American Standard

Scope of Application

This machine is used for the point-to-point resistivity test of anti-static work clothes and anti-static fabrics, complying with different testing standards such as national standards and European standards. It is equipped with the TEST V1.6 dedicated testing software, which can realize online operation, automatically complete the sample test according to the standard regulations, process the test results, edit and print the test reports.

Instrument Configuration

Standard configuration of the instrument:

(1) 1 set of computer operating system software

(2) 1 main unit of the tester

(3) 1 set of standard point-to-point heavy hammer electrodes for the instrument

(4) 1 set of standard ring combination electrodes for the instrument

(5) 2 measurement cables; 1 power cord.

(6) 1 user manual;

(7) 1 certificate of conformity;

(8) 1 packing list.

Technical Parameters

Resistance measurement range: 104Ω ~ 1016Ω.

LCD display: Surface resistance, temperature, current, voltage, test time, and test sample data can be input; units can be switched (mm, cm, m).

Built-in test voltage: Any value from 0 - 1000V can be set.

Basic accuracy: < 1G ± 1%; >= 1G ± 3%; >= 1T ± 10%. The accuracy deviation values in different ranges are different.

Operating environment: Temperature: 0℃ ~ 40℃, relative humidity < 80%.

Internal test voltage: Any value from 10/50/100/250/500/1000V can be set.

Power supply: AC 220V, 50HZ, power consumption is about 5W.

Measurement mode: Manual/automatic range. With PC testing software (optional), USB communication interface, and the software interface synchronously displays, analyzes, saves and prints data!

Common electrode (fixture) device options:

Type A: Heavy hammer electrode (for point-to-point resistance test of fabric surface)

Type B: Ring combination electrode (for fabric surface resistivity test and fabric vertical resistance test)

Dimensions of the main unit: 330mm * 340mm * 120mm
